Sheet Metal Enclosure Fire Extinguisher Box Production Line

Automatic stainless steel enclosure & Mild steel sheet enclosure enclosure fire extinguisher box production line manufacturer

Product Description

Stainless steel enclosure & Mild steel Sheet Metal Enclosure Fire Extinguisher Box Production Line


Equipment for producting mild steel fire extinguisher cabinets box with different dimension available.


Painted roll forming machine for making sheet emtal enclosure Fire extinguisher cabinets & box  photo

Sheet Metal Enclosure Fire Extinguisher Box Production Line




1,  Fire extinguisher box production line technical parameters


No.ITEMPARAMETERREMARK
1MATERIALTypeMS Steel
T.(mm)0.9-1.2mm
Yield Strength (Mpa)Q235
2Forming product   WidthCustomized
3Forming speed   (m/min)6-13mIncluding hole
4Forming main power   (KW)7.5 KWFYR
5Hydraulic power   (KW)18.5 KWFYR
6Bending power (KW)3 KWFYR
7Voltage AC380V,50Hz,3P


Fire exguisher case production line process

Uncoiler →Straightening→servo feeder→Hydraulic press breach device  → Guide device → roll forming machine → hydraulic punch → Bending enclosure (optional)→shear device (including knife)→ finished product rack


Roll Forming machine list


Uncoiler, Straightener

1,Type Manual Expansion

2,Parameter

1) Passive   discharge

2) Coil weight:<   2T

3) Coil inner D.:φ450mm-φ530mm

4) Max. Width.400mm

5) Thickness .0.4-1.6mm

6) Straightener roller :9 pcs

7) Power.1.5kw

Sheet Metal Enclosure Fire Extinguisher Box Production Line


Servo Feeder

3.1 Max. feeding width 400mm
3.2  Feeding thickess 0.4-1.6mm

3. 3  Motor , 1.3KW(Yaskawa)


Hydraulic hole punching system

3.1 Function:Hydraulic punch breach  (Mould 1 set)
3.2 Structure: set the length, automatic length measurement, automatic positioning reaches the set distance stop action , hydraulic cylinder driven punching die, stamping automatic shutdown.
3.3 Hydraulic system working pressure:16MPa
3.4 Hydraulic station:18.5KW( Hydraulic punch hole/shear use same station)

A. Hydraulic punch for the panel gap.

B. Hydraulic punch for the knock down hole

C. Hydraulic punch for the ventilating hole.

Sheet Metal Enclosure Fire Extinguisher Box Production Line


Guide device



Main Forming machines  (Panel width adjustable)


5.1  Forming Roller:16 stations,and add Rub-roll, To make sure the surface profile no scratches.

5.2  Side Panel:T.18mm ,A3 steel   Heavy duty 。

5.3  Rolling speeding: 6-12 m/min。

5.4  Roller material:GCr15,overall quenching, hardness HRC56-62 ℃.
5.5  Motor power:7.5KW。
5.6  Main Roller :Dia.75mm,45 #。
5.7  Equipment base: 45 # H type using welded steel plate.
5.8  Transmission: chain drive.
5.9 Security: across the board with emergency stop buttons, easy to handle emergencies, to ensure that equipment and operator safety. And other gear in the chain and the staff could easily lead to injury transmission section covered with protective cover, to ensure the safety of workers.

5.10 Flat collect rack

5.11 Box Bending Machine (including mould)

Sheet Metal Enclosure Fire Extinguisher Box Production Line


Electrical control system
The entire line imported PLC control, LCD touch screen, man-machine interface. People interact with the PLC. Operator setting the program to run automatically (programmable control) and control process monitoring, production line operator control and modify the control parameters, and real-time monitoring the equipment status & parameters and fault indication. Workpiece length digital setting, adjustable length can be adjustable as well. Real-time monitoring of equipment operating status and fault indication.
Operation manual / automatic two styles. With manual and automatic switching function: In the manual mode, can be stand-alone operation, easy maintenance; In automatic mode, carry out full production run, in order to start; across the board with emergency stop buttons, easy to handle emergencies, to ensure that equipment and operating personnel Safety.

Machinery main components of the brand:
PLC control system: Siemens
Inverter: Taiwan Shilin
Encoder: Omron
Touch screen: Siemens
Some components are Schneider brand devices.


Devices completed extinguisher cabinet prodution line


No.Machine nameQTYREMARK
1Uncoiler, straightener1
2Servo Feeder1
3Hydraulic   machine2With mould
4Guide device1
5Forming machine1
6Hydraulic station2
7Follow Shear1Including knife
8Collect rack1
9Control system2
10Box bending device1With mould


 Steel extinguisher box machine accessories brand

No.Namemanufacturer
1Motor & ReducerDomestic brands
2The main key bearingDomestic brands
3InverterShilin
4PLC SystemsSiemens
5Low-voltage electricalSchneider
6EncoderOmron
7touch screenSiemens
8Hydraulic systemDomestic brands
