Fluorescent lampshade roll forming machine

New design full automatic metal fluorescent lampshade roll forming machine for fluorescent or LED light

Product Description

Fluorescent lampshade roll forming machine

New design full automatic metal fluorescent lampshade roll forming machine for fluorescent or LED light


Ⅰ,Steel Lampshade design photo

Fluorescent lampshade roll forming machine


Ⅱ, Lampshade production line process

Uncoiler  → Guide device → roll forming machine →shear device (including knife)→ finished product rack


Layout as below


Rack shelf roll forming machine

Ⅲ, Machines List


(Ⅰ), Uncoiler

1、 Type:Manual Expansion

2、Parameter

1)Passive   discharge

2) Coil weight:<   2T

3)Coil inner D.:φ450mm-φ530mm

4)Max. Width.400mm

5)   Thickness .0.4-1.6mm


(Ⅳ) Guide device



(Ⅴ)Main Forming machines


5.1  Forming Roller:16 stations,and add Rub-roll, To make sure the surface profile no scratches.

5.2  Side Panel:T.18mm ,A3 steel   Heavy duty 。

5.3  Rolling speeding: 12-15 m/min。

5.4  Roller material:#45,overall quenching, hardness HRC56-62 ℃.
5.5  Motor power:5.5KW。
5.6  Main Roller :¢75mm,45 #。
5.7  Equipment base: 45 # H type using welded steel plate.
5.8  Transmission: chain drive.
5.9 Security: across the board with emergency stop buttons, easy to handle emergencies, to ensure that equipment and operator safety. And other gear in the chain and the staff could easily lead to injury transmission section covered with protective cover, to ensure the safety of workers.

Fluorescent lampshade roll forming machine



(Ⅵ),Flat collect rack


(Ⅷ),Electrical control system
The entire line imported PLC control, LCD touch screen, man-machine interface. People interact with the PLC. Operator setting the program to run automatically (programmable control) and control process monitoring, production line operator control and modify the control parameters, and real-time monitoring the equipment status & parameters and fault indication. Workpiece length digital setting, adjustable length can be adjustable as well. Real-time monitoring of equipment operating status and fault indication.
Operation manual / automatic two styles. With manual and automatic switching function: In the manual mode, can be stand-alone operation, easy maintenance; In automatic mode, carry out full production run, in order to start; across the board with emergency stop buttons, easy to handle emergencies, to ensure that equipment and operating personnel Safety.

Machinery main components of the brand:
PLC control system: Siemens
Inverter: Taiwan Shilin
Encoder: Omron
Touch screen: Siemens


Some components are Schneider brand devices.



Ⅴ,Devices completed light lampshade prodution line


No.Machine nameQTYREMARK
1Uncoiler   straightener1
3Hydraulic   machine1With mould
4Guide device1
5Forming machine1
7Follow Shear1Including knife
8Collect rack1
9Control system1


Ⅵ, Lampshade forming machine accessories brand


No.Namemanufacturer
1Motor & ReducerDomestic brands
2The main key bearingDomestic brands
3InverterShilin
4PLC SystemsSiemens
5Low-voltage electricalSchneider
6EncoderOmron
7touch screenSiemens
8Hydraulic systemDomestic brands




Product Features

Guarantee of Quality

Superda guarantee illumination shade roll forming line design accordance with clients required drawing, machine is brand new. Specification and performance as stipulated in drawing and operation with good smooth.

Fluorescent lampshade roll forming machine


Rack metal shade produciton equipment advantage

1, Rack shelf production line for producing light storage shelves, medium storage shelves, heavy storage shelves.

2, PLC control system, automatically and easy handle.

3, Good quality roller with quench process, hardness reach HRC58-62 ℃.

4,Tracking cutting system with Cr12 Cutting blade.



Model and Meaning

Equipment for production illumination metal shade.

Fluorescent lampshade roll forming machine

New design machine solution roll former for producing metal fluorescent lampshade with europe CE certification. Machine design for width 80-200mm and thickness from 0.8-1.2mm. Machine is very advantage in safety operation across the board with emergency stop buttons, easy to handle emergencies, to ensure that equipment and operator safety. And other gear in the chain and the staff could easily lead to injury transmission section covered with protective cover, to ensure the safety of workers.




Technical Parameters

Stee fluorescent lampshade roll forming machine

Technical parameters

No.

ITEM

PARAMETER

REMARK

1

MATERIAL

Type

Cold-rolled strip steel, galvanized sheet


T.(mm)

0.8-1.2mm


Material strength

G300 MPA


2

Forming speed   (m/min)

12-15m

Including hole

3

Forming main power   (KW)

5.5KW

FYR

4

Hydraulic power (KW)

15KW

FYR

5

Total Power

          20.5KW

FYR

6

Voltage

 AC380V,50Hz,3Phase

Customized
