Equipment for production channel profile & Z purlin roll forming machine

Equipment for production channel profile & Z purlin roll forming machine, Galvanized steel channel process machinery for sale.

Product Description

Equipment for production channel profile & Z purlin roll forming machine, Galvanized steel channel process machinery for sale.

In addition to C-type light steel, Z purlin steel has been widely used in the construction of commercial projects in the world


Ⅰ,Customized Z purlin



Ⅱ, Hat profile production line process

Uncoiler straightener 2 in 1 → Guide device → roll forming machine →shear device (including knife)→ finished product rack

Equipment for production channel profile


Layout as below

Steel Frame Roll Forming Machine


Ⅲ, Machines List


(Ⅰ), 2 in 1 Uncoiler   straightener

1、 Type:Manual Expansion

2、Parameter

1)Passive   discharge

2) Coil weight:<   2T

3)Coil inner D.:φ450mm-φ530mm

4)Max. Width.400mm

5)   Thickness .0.4-1.6mm

6)   Straightener roller :7 pcs

8)   Power.1.5kw



(Ⅱ),Servo Feeder
3.1 Max. feeding width:400mm
       3.2  Feeding thickess: 0.4-1.6mm

       3. 3  Motor , 1.3KW(Yaskawa)



(Ⅳ) Guide device



(Ⅴ)Main Forming machines  (for panel width 65mm with reinforcemnt design )


5.1  Forming Roller:18 stations,and add Rub-roll, To make sure the surface profile no scratches.

5.2  Side Panel:T.18mm ,A3 steel   Heavy duty 。

5.3  Rolling speeding: 8-12 m/min。

5.4  Roller material:#45,overall quenching, hardness HRC55-60 ℃.
5.5  Motor power:7.5KW。
5.6  Main Roller :¢65mm,45 #。
5.7  Equipment base: 400# H type using welded steel plate.
5.8  Transmission: chain drive.
5.9 Security: across the board with emergency stop buttons, easy to handle emergencies, to ensure that equipment and operator safety. And other gear in the chain and the staff could easily lead to injury transmission section covered with protective cover, to ensure the safety of workers.

Equipment for production channel profile



(Ⅵ),Flat collect rack


(Ⅷ),Electrical control system
The entire line imported PLC control, LCD touch screen, man-machine interface. People interact with the PLC. Operator setting the program to run automatically (programmable control) and control process monitoring, production line operator control and modify the control parameters, and real-time monitoring the equipment status & parameters and fault indication. Workpiece length digital setting, adjustable length can be adjustable as well. Real-time monitoring of equipment operating status and fault indication.
Operation manual / automatic two styles. With manual and automatic switching function: In the manual mode, can be stand-alone operation, easy maintenance; In automatic mode, carry out full production run, in order to start; across the board with emergency stop buttons, easy to handle emergencies, to ensure that equipment and operating personnel Safety.

Machinery main components of the brand:
PLC control system: Siemens
Inverter: Taiwan Shilin
Encoder: Omron
Touch screen: Siemens


Some components are Schneider brand devices.



Ⅴ,Devices completed drywal CU Channel frame metal stud production line


No.Machine nameQTYREMARK
1Uncoiler   straightener1
2Servo Feeder1
4Guide device1
5Forming machine1
7Follow Shear1Including knife
8Collect rack1
9Control system1


Ⅵ, Metal frame machine accessories brand

No.Namemanufacturer
1Motor & ReducerDomestic brands
2The main key bearingDomestic brands
3InverterShilin
4PLC SystemsSiemens
5Low-voltage electricalSchneider
6EncoderOmron
7touch screenSiemens
8Hydraulic systemDomestic brands


Product Features

Guarantee of Quality

Superda guarantee metal frame roll forming line design accordance with clients required drawing, machine is brand new. Specification and performance as stipulated in drawing and operation with good smooth. Formed metal frame can be fix well with each other metal parts.

Drywall profile channel roll forming machine for C Z U channel


Steel frame roll forming machine advantage

1, Steel frame production line for producing metal frame.

2, PLC control system, automatically and easy handle.

3, Good quality roller with quench process, hardness reach HRC55-60℃.

4,Tracking cutting system with Cr12 Cutting blade.



Model and Meaning

Item Z purlin roll forming machine

Z profile steel frames are lightweight steel frame.

Steel frame application

Steel frame is widely in using building. there are skeleton frame,vertical steel columns, and horizontal beams. adpot to support the floors, roof and walls of a building which are names as steel frame.

Galvanized steel frame can be roll formed as steel studs for use as a structural or non-structural building material for both external and partition walls in both residential, commercial and industrial construction projects. The dimension of the room is established with horizontal track that is anchored to the floor and ceiling to outline each room. Customized steel frame stud and track with reinforcement.

1. The light steel skeleton is divided into two types: U-shaped skeleton and T-shaped skeleton, and is divided into people according to the load.

2. The main components of the light steel skeleton are large, medium and small keels; the accessories have hanging parts, connecting pieces and hanging inserts.

Channel roll former top hat purlin forming machine supplier

Technical Parameters

Metal top hat hannel steel stud and track roll forming machine for production different size metal frame


Technical parameters

No.

ITEM

PARAMETER

REMARK

1

MATERIAL

Type

Cold-rolled strip steel, galvanized sheet


T.(mm)

0.6-1.0mm


Yield Strength

G245MPa


2

Forming product   Width

Z


3

Forming speed   (m/min)

10-15m


4

Forming main power   (KW)

7.5 KW

FYR

5

Hydraulic power   (KW)

7.5 KW

FYR

7

Voltage

 AC380V,50Hz,3P

Custimized
