Door frame roll forming machine

High quality steel door frame roll forming machine manufacturer China. door frame forming machine can automatically control the length, quantity, forming, cutting.

Product Description

Steel door frame roll forming machine manufacturer China

1, Door frame machine for producing steel door frame shapes

Door frame roll forming machine

2,Completed door frame production line working flow ,

Decoiler —guiding — feeding — roll forming — finished product

factory production layout for reference.

Door shutter roll forming machine

3,Equipment consists

The equipment consist with de-coiler , leveling machine, servo feeding

machine, main forming machine, cutting device, collection table .PLC control system

4,Main technical parameter of production line ,

material : GI steel sheet, low carbon steel.

the thickness of the steel sheet , 1.5mm

inner diameter of coil , Φ508mm

line speed, 8-12m/min ( adjustable)

5. The characteristic of the machine

5.1 Metal strip coil de-coiler ,

functional and structural features,

be used to support and expansion steel coiler , section steel welding fuselage. it is easy to operate.

technical parameters

    material inner diameter : φ508mm

    range of inner diameter : ф450-550

    maximum outer diameter: φ1200mm

    load capacity: ≤ 5T

Cable tray roll forming machine manufacturer

5.4 Servo feeding machine

F  type : servo feeding

F  functions and Structure: Pinch and be with steel to the press machine. Polyurethane roller ensure that the feeding force. Feeding  each error of feeding be controlled in rang of ± 0.15mm. Compared with the servo Clamp, feed length setting is more flexible, adapt to a wider range. This feeding device is more suitable for wide material , can effectively improve the feeding accuracy. Servo motor, measuring devices, digital control system are the imported components.

technical parameters:

maximum number of feeding: 30 ~ 40 times / min (adjustable)

feeding step: 100MM / step (adjustable).


5.10 Forming machine :

type: double cantilever gear drive, width adjustable universal forming machine and the overall mobile, fast (waist height and width) exchange specifications.

Forming Roller:16 stations,and add Rub-roll, To make sure the surface profile no scratches.
Side Panel:T.18mm ,A3 steel   Heavy duty 。

Rolling speeding: 8-12 m/min。

Roller material:#45 bearing steel,overall quenching, hardness HRC56-62 ℃.
Motor power:11KW。
Main Roller :¢75mm,45 #。
Equipment base: 35 # H type using welded steel plate.
Transmission: chain drive.
Security: across the board with emergency stop buttons, easy to handle emergencies, to ensure that equipment and operator safety. And other gear in the chain and the staff could easily lead to injury transmission section covered with protective cover, to ensure the safety of workers.

Door frame roll forming machine

5.11 Collection table

type: Finished cable tray arrive collection table, worker will collect products , non-powered roller.

function and structure: consist of section steel (square pipe), no power roller assembly, welding, play a role in supporting finished product ,can adapt 8-meter finished product.


5.12 Electrical control system

the whole line adopt imported PLC control , touch screen be used for human-machine interface,  achieving the interaction between man and PLC.

Cable Tray Machine

Product Features

Door frame roll forming machine

1, Door frame production line for producing steel door industry metal sections.

2, PLC control system, automatically and easy handle.

3,Bearing steel roller with quench process, hardness reach HRC60-65 ℃.

4,Tracking cutting system with Cr12 Cutting blade.

Model and Meaning

Model, YX-150

Door frame roll forming machine machine is the equipment for production metal door frame.

How to producing steel door frame, by door frame forming machine is nice solution equipment for make sure the length, straightness, smoothness, shape and contour definition of the door frame. The door frame forming machine can automatically control the length, quantity, forming, cutting, discharging, cutting and other functions.

Technical Parameters

Door frame roll forming machine parameter data

Door frame forming machine
Material Thickness1.5MM
Roller Material#45
Shaft Material35# H steel
Forming Speed8-12m/min
Control SystemPLC Control( Delta brand)
Total Power11kw
Tolerance Cutting
Rated VoltageCustomized
Machine size
Machine weight4500kgs
