Smoke Exhaust Valve Roll Forming Machine

280 Centigrade Fuse Type Smoke Exhaust Valve & Fir Damper Blade & Anti-fire Valve metal panel roll forming machine

Product Description

Smoke Exhaust Valve Roll Forming Machine, anti-backfire valve, electrical smoke exhaust valve, fire damper blade fabricating machine

Fire Damper Valve Panel roll forming machine parameter

1MATERIALTypeCold-rolled strip steel, galvanized sheet
Yield Strength (Mpa)Q235,Q350
2Forming product   WidthDepend on drawing
3Forming speed   (m/min)12-15m
4Forming main power   (KW)7.5 KWFYR
5Hydraulic power   (KW)7.5 KWFYR
6Hydraulic press 20Mpa
7Voltage AC380V,50Hz,3PCustomized

Completed steel door production line working flow ,

Decoiler —Straightener—Guiding — Feeding — Roll forming — Finished product

Metal Door Equipment consists

The equipment consist with de-coiler , leveling machine, servo feeding

machine, main forming machine, cutting device, collection table .PLC control system

4,Main technical parameter of production line ,

material : GI steel sheet, low carbon steel.

the thickness of the steel sheet , 1.5mm

inner diameter of coil , Φ508mm

line speed, 8-12m/min ( adjustable)

5. The characteristic of the machine

5.1 Metal strip coil de-coiler ,

functional and structural features,

be used to support and expansion steel coiler , section steel welding fuselage. it is easy to operate.

technical parameters

    material inner diameter : φ508mm

    range of inner diameter : ф450-550

    maximum outer diameter: φ1200mm

    load capacity: ≤ 5T

Smoke Exhaust Valve Roll Forming Machine

5.4 Servo feeding machine

Type : servo feeding

Functions and Structure: Pinch and be with steel to the press machine. Polyurethane roller ensure that the feeding force. Feeding  each error of feeding be controlled in rang of ± 0.15mm. Compared with the servo Clamp, feed length setting is more flexible, adapt to a wider range. This feeding device is more suitable for wide material , can effectively improve the feeding accuracy. Servo motor, measuring devices, digital control system are the imported components.

technical parameters:

maximum number of feeding: 30 ~ 40 times / min (adjustable)

feeding step: 100MM / step (adjustable).


5.10 Forming machine :

type: double cantilever gear drive, width adjustable universal forming machine and the overall mobile, fast (waist height and width) exchange specifications.

Forming Roller:16 stations,and add Rub-roll, To make sure the surface profile no scratches.
Side Panel:T.18mm ,A3 steel   Heavy duty 。

Rolling speeding: 8-12 m/min。

Roller material:#45 bearing steel,overall quenching, hardness HRC56-62 ℃.
Motor power:7.5KW。
Main Roller :¢75mm,45 #。
Equipment base: 35 # H type using welded steel plate.
Transmission: chain drive.
Security: across the board with emergency stop buttons, easy to handle emergencies, to ensure that equipment and operator safety. And other gear in the chain and the staff could easily lead to injury transmission section covered with protective cover, to ensure the safety of workers.

Smoke Exhaust Valve Roll Forming Machine

5,11 Collection table

type, Finished cable tray arrive collection table, worker will collect products , non-powered roller.

function and structure: consist of section steel (square pipe), no power roller assembly, welding, play a role in supporting finished product ,can adapt 8-meter finished product.


5.12 Electrical control system

the whole line adopt imported PLC control , touch screen be used for human-machine interface,  achieving the interaction between man and PLC.

Ⅴ,Devices completed steel door panel prodution line

No.Machine nameQTYREMARK
1Uncoiler 1Manual
2Servo Feeder1
4Guide device1
5Forming machine1
7Follow Shear1Including knife
8Collect rack1
9Control system1

Ⅵ, Door panel making machine accessories brand

1Motor & ReducerDomestic brands
2The main key bearingDomestic brands
4PLC SystemsSiemens
5Low-voltage electricalSchneider
7touch screenSiemens
8Hydraulic systemDomestic brands
